Hydac Hydraulic Filter Element 0330 R 040 Am

Supply Product Series:
-Hydraulic Filters & Element
-Precision Filter Element
-Air Compressor Filter
-Oil Purification Equipment & Element
-Other Filters & Hydraulic Accessories
We can manufacture filter as your requirement .Please kindly advise photo and size . Welcome OEM & ODM !
Welcome OEM ! Kindly inform us following information
1,Photo
2,ID,OD,Height
3,Filtration Precision
4,End Cap
WELCOME TO VISIT OUR FACTORY AND OUR CITY!

Basically, hydraulic oil filter is a device containing three types of filter media layers, namely: metal, paper and micro glass elements. As hydraulic oil passes through the filter, it traps and removes particulate matter.

As a result, it prevents ingress of foreign particles that may cause damage to hydraulic system.


Working Principle of Hydraulic Oil Filter

Hydraulic fluid serves a number of purposes in hydraulic systems. Undoubtedly, its core role is to transfer force to the actuators from the hydraulic power unit. However, it also does the following: · To keep the system surface lubricated to avoid friction on metal surface on each other. · Maintain a conducive temperature by transferring from one end to the other. · Seals the hydraulic system through adhesion and surface tension.


Selection criteria of hydraulic filters depends upon:

* The maximum flow rate permissible through the filter.
* Maximum operating pressure that the filter can withstand.
* Port size of the inlet and outlet ports which need to connect to the hydraulic fluid system.


Features of Hydraulic Oil Filter

· High resistance to variable operating pressures and flow rates · Wide range of micron rating∶ from 1μm to 500μm · Improved system reliability and lower maintenance costs · Customized hydraulic oil filters for specific filtration requests

· More pleats and surface area for a higher dirt-holding capacity

· Consistent filter efficiency to remove particles and water,even at a high differential pressure · Compatible with a wide range of fluid types,such as mineral oils, emulsions and most synthetic hydraulic oils

Description
(1)The quality and performance can be guaranteed as original elements.
(2)Filter accuracy: 1um, 3um, 5um, 10um, 20um, 25um, 40um, 50um, 80um, 100um, 150um, 200um
(3)Filter material: Glass fiber, filter paper, stainless steel wire mesh.
(4)End caps material: Carbon steel & stainless steel & Aluminum & Nylon & NBS.
(5) Temperature range: -4°F~212°F
(6) Collapse pressure rating: 21bar-210bar (Hydraulic Liquid Filtration)
(7) O-ring Material: VITON, NBR.
(8) Working medium: hydraulic oil
